Removing and installing steel spring strut: VW Touareg II
Step-by-step removing and installing steel spring strut for the VW Touareg II: 22 steps, 1 torque figure.
Workshop procedure for VW — the exact step sequence and torque figures, straight from real workshop data.
🧭 Before you start
Fits: VW Touareg II (7P, 2010–2018)
🔩 Torque settings
Values can differ between engine variants — check the code stamped on your block.
| Torque | Fastener / step |
|---|---|
| 50 Nm (37 lb-ft) | Tighten bolts (1) to (4) |
ℹ️ Always cross-check the exact figure against your vehicle's factory manual before final tightening — a wrong torque can damage the engine. These values are extracted from workshop data and may not cover every variant or revision.
📋 Procedure
- Remove floor of luggage compartmentGeneral body repairs, interior70Luggage compartment panelling.
- Remove mounting plate for floor of luggage compartmentGeneral body repairs, interior70Luggage compartment panelling.
- Remove plugs above bolted connections of steel spring strut.
- Unscrew and remove bolted connections (arrows) of steel spring strut.
- Undo bolted connection (arrow) between steel spring strut (1) and coupling rod at wheel bearing housing.
- Insert wooden beam between subframe (1) and upper rear transverse link (2).
- Press axle down with wooden beam.
- Remove bolt.
- Remove steel spring strut.
- Insert steel spring strut with guide bolts (arrows A) into upper holes (arrows B) in body.
- Hand-tighten bolts (arrows) at strut support.
- Insert wooden beam between subframe (1) and upper rear transverse link (2).
- Press axle down with wooden beam.
- Insert steel spring strut (1) in wheel bearing housing.
- Insert bolt (arrow) between steel spring strut (1) and coupling rod at wheel bearing housing.
- Hand-tighten bolt.
- Tighten bolts (1) to (4) to 50 Nm in sequence shown. — 50 Nm (37 lb-ft)
- Then tighten bolts (1) to (4) 180° further in sequence shown.
- Tighten bolts (1) to (4) to 50 Nm in sequence shown. — 50 Nm (37 lb-ft)
- Then tighten bolts (1) to (4) 180° further in sequence shown.
- Tighten bolts on lower steel spring damper.
- Install wheel and tighten bolts or nuts .
