Removing and installing track rod ball joint: VW Touareg II
Step-by-step removing and installing track rod ball joint for the VW Touareg II: 15 steps. What to remove, in what order, and what to check after.
Workshop procedure for VW — the exact step sequence and torque figures, straight from real workshop data.
🧭 Before you start
Fits: VW Touareg II (7P, 2010–2018)
Don't miss
- Mark position of track rod ball joint on track rod.
- Loosen nut on track rod ball joint but do not remove completely.
- Make sure that correct track rod ball joint is installed on each side.
- Screw track rod ball joint onto track rod as far as previously applied mark and secure with lock nut.
📋 Procedure
- Activate car jacking mode and place vehicle on lifting platform .
- Loosen wheel bolts.
- Raise vehicle.
- Remove wheel.
- Loosen nut (1).
- Mark position of track rod ball joint on track rod.
- Loosen nut on track rod ball joint but do not remove completely.
- ⚠ Leave nut screwed on a few turns to protect thread on pin. — Push track rod off wheel bearing housing and remove nut.
- Unscrew track rod ball joint from track rod.
- Make sure that correct track rod ball joint is installed on each side.
- Screw track rod ball joint onto track rod as far as previously applied mark and secure with lock nut.
- Insert track rod ball joint into wheel bearing housing.
- Bolt track rod ball joint with new nut.
- Install wheel and tighten bolts or nuts .
- Check wheel alignment after completing the installation .
