Removing and installing air filter element - engines with code letters CDLA, CDLB and CDMA — AUDI

🧭 Before you start

Fits: Audi TT Mk2 (8J, 2006–2014)

Don't miss

• Ensure secure fit of intake hose at air mass meter.

🔧 Engine codes this applies to

📐 56 workshop diagrams for BPY

Real factory drawings for this job — timing marks, bolt locations and routing. Locked in the free view.

📋 Procedure

1. Detach air intake hose (1) at air mass meter G70.
2. Unplug electrical connector (2) at air mass meter G70.
3. Unbolt air cleaner (top section) (arrows) and take out air filter element. [Note: If the air filter element is very dirty or wet, dirt or water could reach the air mass meter and affect the air mass value. This would lead to loss of power, since a smaller injection quantity is calculated.Always use genuine part for air filter element.The air cleaner housing MUST be clean.Secure all hose connections with the correct type of hose clips (same as original equipment) Electronic parts catalogue.To prevent malfunctions, cover all critical parts of the engine air intake tract (air mass meter, intake pipes, etc.) with a clean cloth when blowing out the air cleaner housing with compressed air.Please observe requirements for disposal.]
4. Blow out water drain (small hole in bottom section of air cleaner) with compressed air.
5. Clean salt residue, dirt and leaves out of air cleaner housing (top and bottom sections); use a vacuum cleaner if necessary.

6. Check for salt residue, dirt and leaves in air mass meter and air hose (engine intake side).
7. Check for dirt and leaves in air duct going from lock carrier to air cleaner housing.
8. When installing the air filter element, check that it is properly centred in the retainer in the air cleaner (bottom section).
9. Fit the top section of the air cleaner carefully on the bottom section, without using force. Make sure the top section of the air cleaner is fitted straight on the air filter element (note position of sealing lip on air filter element).
10. Ensure secure fit of intake hose at air mass meter.
